Luva do cabo do ANIMAL DE ESTIMAÇÃO
Created with Pixso.

Flame Retardant High Flexibility Abrasion Resistant PET Braided Cable Sleeve for Wire Harness Protection

Flame Retardant High Flexibility Abrasion Resistant PET Braided Cable Sleeve for Wire Harness Protection

Nome da marca: None
Número do modelo: 5mm5m
MOQ: 1
preço: negotiable
Condições de pagamento: L/C,D/A,D/P,T/T,Western Union
Capacidade de Fornecimento: 500.000 milhões por dia
Informações pormenorizadas
Lugar de origem:
Jangsu China
Certificação:
ISO9001
Material:
BICHO DE ESTIMAÇÃO
Temperatura operacional:
-50 a 150ºC
Inflamabilidade:
Alta inflamabilidade
Retardador de chama:
Autoextinguível
Amigo do ambiente:
Livre de halogênio, ecologicamente correto
Cor:
Preto, roxo, azul, amarelo, vermelho, rosa, cinza, marrom, branco e assim por diante
Tamanho:
5mm ,6mm ,10mm ,12mm ,15mm ,16mm ,25mm até 65mm ,outro tamanho pode ser personalizado mediante solic
Desempenho:
Alta resistência expansível
Resistência à tracção:
Boa elasticidade e tração
Ponto de fusão:
250ºC
Flexibilidade:
Excelente flexibilidade, fácil de dobrar ou arranhar
Detalhes da embalagem:
Caixa
Habilidade da fonte:
500.000 milhões por dia
Destacar:

flame retardant PET cable sleeve

,

abrasion resistant braided cable sleeve

,

high flexibility wire harness protector

Descrição do produto
UL94 High Flexible PET Braided Cable Sleeve
Product Overview

PET braided expandable sleeving, also known as PET braided mesh tube or snake skin tube, is woven from high-tenacity eco-friendly PET monofilament. This versatile solution is widely used for wire harness protection, management, and finishing, offering excellent flexibility, abrasion resistance, and heat dissipation capabilities.

Material & Construction
Material
High-tenacity eco-friendly PET polyester monofilament
Structure
Open braided construction with high elasticity
Expansion Ratio
Up to 1.5 times of original diameter
Technical Specifications
Operating Temperature
-50°C to 150°C
Melting Point
240±10°C
Flammability Rating
UL94 V-2, VW-1
Environmental Compliance
RoHS, Halogen-free
Key Features
  • Highly flexible and expandable
  • Abrasion-resistant construction
  • Flame-retardant properties
  • Breathable design for heat dissipation
  • Anti-aging and chemical-resistant
Available Specifications

Flat Widths: 3mm, 6mm, 8mm, 10mm, 12mm, 16mm, 20mm - 76mm

Standard Colors: Black, white, gray, red, blue, yellow, transparent

Applications
Electronics & Computers
Power cords, internal wiring, HDMI/USB/network cables, server equipment
Automotive & Rail
Engine harnesses, interior wiring, EV high voltage cables, charging pipes
Home Appliances
Air conditioners, refrigerators, washing machines, TVs, ovens
Industrial Equipment
Robots, automation machines, control cabinets, medical devices
Communication
Base stations, fiber jumpers, data center cables, optical equipment
Other Industries
Aerospace, marine wiring, audio engineering, stage lighting
